MS403 PRO

E4

Description

A versatile tread design with an adjusted tread crown for better load distribution. Extra-deep tread depth allows flexibility in applications from smooth haul roads to rough and rocky terrain while providing maximum productivity.

Features

Excellent traction in all haul road conditions
Adjusted tread crown for enhanced load distrubtion and prevents shoulder separations
E4+ extra-deep tread for longest tire life and high TKPH/TMPH
Optimized lower sidewall profile to prevent potential separation in the area
Wide, square footprint distributes load for minimal haul road disturbance
Reinforced bead, shoulder and sidewall for increased cut resistance
Heat-resistant undertread reduces tire temperature
Multiple tread compound options target specific site requirements

Downloads

Applications

Size	Rating	Type	Rim	O.D.	S.W.	T.D.	Tread Compound	TMPH/TKPH	Infl.	L.C.C.	L.I.
33.00R51	**	TL	24.00/5.0	120.5 3061	36.4 925	106 84	Ultra Cut Resistant	331/483	102 (108)*	85500 (90940)*	235B (237B)*
33.00R51	**	TL	24.00/5.0	120.5 3061	36.4 925	106 84	Cut Resistant	408/595	102 (108)*	85500 (90940)*	235B (237B)*
33.00R51	**	TL	24.00/5.0	120.5 3061	36.4 925	106 84	Standard	480/700	700(750)*	38750 (41250)*	235B (237B)*
33.00R51	**	TL	24.00/5.0	120.5 3061	36.4 925	106 84	Heat Resistant	550/802	700(750)*	38750 (41250)*	235B (237B)*

* Consult a Maxam representative if the 237B loading condition is required.
